Continuous Tray Dryer

Home / Products / Continuous Tray Dryer

Overview


A revolutionary concept in drying of powder, granules, pellets & tablets in a continuous, cost effective, efficient manner with minimum human interference.

In a Continuous Tray Dryer material charging is from top and from 01 plate to another plate it keeps on tumbling thereby all the portions of the material is subjected to hot air and dried product is disposed from bottom with no human interference thereby avoiding problem of contamination.

Continuous output can be achieved from continuous Tray Dryer enhancing overall production. The working principle of continuous Tray Dryer is a mixed system of tray dryer and conveyor dryer. The system has continuous trolleys. Products can be dried by using different air sections (bottom - top - right - left). Each trolleys stay at all of air sections by using continuous trolley system.

More info


Technical Specifications for Continuous Tray Dryer:

CONTINUOUS ROTARY TRAY DRYER CAPACITY 30-50Kg/hr
BLOWER POWER 3.2 KW>
COMPRESSED AIR MOTOR POWER NIL
STEAM CONSUMPTION 60 Kg/hr
POWER CONSUMPTION PER HOUR 3.20 UNITS
ELECTRICITY COST PER HOUR Rs 24.00
MANPOWER REQUIRED 1-2


  • Circular Feeder driven by geared motor
  • Geared motor drive for the rotation of rotary plates
  • Motor driven Timer belt drive for Lamina Flow Air Distribution System
  • Self standing body with jacketed interiors for insulation
  • 18 tray arrangement one above the another on a trolley which can be rolled to washing area
  • Air Exhaust port provided
  • Air Handling Unit for Inlet Air with steam heating provision
  • Built in electrical panel
  • PLC control system.

  • Agricultural chemicals
  • Fertilizers
  • Agrochemicals
  • Carbon black
  • Ceramics
  • Atomic tablets
  • Soya and food processing
  • Home and Personal care.
  • Cosmetics
  • Agglomeration
  • Particle size build up
  • Heat Sensitive materials
  • Pressure sensitive materials
  • Pharmaceuticals
  • Pigment
  • Toner, etc.

    Umang Pharmatech : Pharmaceutical Test Station

    The Umang Pharmaceutech Test Station is located in Vasai, THane, conveniently located very close to Mumbai airport, only forty five minutes from Mumbai International Airport. The Test Station's purpose is to assist our Pharmaceutical and Biopharmaceutical Industry customers with feasibility testing of their products on our equipment, and to be a partner with them in the process development as they move forward from the Research and Development stages to clinical production, and eventually into full-scale Manufacturing.

    The station combines decades of design and development know-how in the pharmaceutical industry with the very latest in processing equipment to provide you with a unique opportunity for feasibility, development, and small-scale manufacturing of pharmaceutical products.

    Your needs are critical and individual. The UMANG Pharmaceutical Test Station has been designed to meet those needs.

    • Product evaluation & testing
    • Demonstration
    • Training
    • Formulation development
    • Process optimization
    • Small-scale manufacturing

    We offer the following process options:

    • Spray drying:
    • High shear mixer
    • Extrusion and spheronization
    • Fluid bed coating and granulation.
    • Fluid bed rotor
    • Cone extrusion.
    • Die roller extrusion.
    • Continuous vibratory fluid bed dryer.
    • fluid-bed granulator - dryer

    Analytical Capabilities

    • Specification development
    • Method development
    • In-process controls
    • Impurity profiling
    • Method validation
    • Stability testing and Degradation studies
    • Release of Intermediates and final product
    • Technology transfer to manufacturing sites
    • Support to regulatory filings
    • Pre-Fo HPLC (Shimadzu) AGilent, RI, Fluoresence Detectors
    • UV-Vis Spectrophotometer
    • Thereo Gravimetric Analyzer (TGA) (Shimadzu)
    • Moisture Analyzer
    • Granulators (Fluid Bed or High Shear)
    • Comminution Mill
    • Diffusion Blenders – V, Octagonal, Double Cone types
    • Multi-purpose equipment - Planetary Mixer, Granulator, Blender attachments
    • Tablet Coating – solid pan of various sizes
    • Pilot Plant for Dermatologicals
    • USP dissolution Apparatus with auto sampler
    • Vertical Cell Diffusion (Franz) Apparatus
    • Tablet: USP Hardness Tester, USP Disintegration Tester & USP Friability Tester
    • Stability Chambers (set to ICH Guidelines)
    • UV-Vis Spectrophotometer
    • FTIR
    • Brookefield Viscometer

    FormulationDevelopment

    Our expertise in formulation development extends to the development of all conventional dosage forms. Our strategic alliances broaden the scope to consider many Novel Drug Delivery Systems (NDDS), including transdermal & liposomal delivery systems. We consider multiple approaches to improve the bioavailability of drugs. We have expertise in improving delivery of poorly soluble/ permeable drugs and the capability to screen potentially innovative drugs based on pharmacokinetic properties. We possess pelletization, drug-layering, particle-coating and other technologies to achieve extended release profiles for tablets or capsules.

    AnalyticalDevelopment

    Our analytical development services include assay and RS method development and validation, dissolution method development and validation, stability studies as per ICH guidelines, polymorphic form characterization (DSC/TGA/XRD/Microscopy), cleaning validation studies and HPLC to UPLC method conversions.

    Generics and NCEs

    • Pre-formulation
    • Proof of Concept studies
    • Phase Appropriate CT Formulations
    • Formulation and Process Development
    • Scale-up and Technology Transfer
    • Life cycle management
    • Differentiated generics, 505 (b) (2)

    Dosage Forms

    • Pellets – Immediate Release, Modified Release
    • Granules – Immediate Release, Modified Release
    • MDF : Mouth Dissolving Film
    • Physico chemical evaluation

    Solubility studies:

    • pH dependent aqueous solubility
    • solubility in co-solvents
    • surfactant assisted solubility
    • equilibrium solubility
    • Intrinsic dissolution study in various pH conditions
    • Salt design/screening and selection
    • Dissociation constant redetermination
    • Partition coefficient and log P determination
    • Polymorphism studies
    • Particle size, surface area, bulk/ tapped density determination
    • Particle size distribution
    • Bulk/tapped density determination
    • Binding constant determination
    • Drug-excipient compatibility studies
    • Containers:
    • Closure integrity testing
    • Filter compatibility
    • Stress stability
    • Photo stability
    • Hold-time study

  • Integration with fluid bed possible: perfect closed link for dust-free operation
  • Video monitoring of the process
  • Liquid addition system (peristaltic pump / pressure vessel)
  • Product feeding both by gravity or vacuum loading system directly from the containers

What is the level of vaccum Achieved in a continuous Tray Dryer ?
750mm

What are the maximum temperature in a continuous tray dryer ?
100̊C.

Can a continuous Tray Dryer dry all products?
Yes under vaccum.

Can we take trials in your laboratory ?
Yes we have a 2 Tray dryer.

Does the recovery assembly come with the machine ?
Yes

Is water circulated under the trays  ?
Yes.

Do you provide consultation productwise ?
Yes.

How quickly can we expect delivery ?
8-10 weeks

Is the machines of modular design ?
Yes it is a modular design.

What type of Maintainence is needed?
The machine is maintainence free.

Can the continuous tray dryer dry powders, granules, pellets, different shapes?
Yes.

Is the main unit of the continuous tray dryer and the recovery unit supplied as the main dryer in processing area and technical area or utlility area.
